Description
Whether plotting your extraction lab, or surrounded by bags of material needing processing, you need an intrinsically safe and reliable way to wash the beneficial oils from the plant and dry the plant matter.
I’ve been designing, assembling, servicing and using centrifuges for the last 12 years. They are remarkably useful machines and I’ve seen them work with many kinds of oil. Whether it be used cooking oil, algae, motor oil and plant extracts, I can confidently say that centrifuges will work magic when needing to separate liquids and solids.
It became clear that our market needed a food grade, safe and reliable centrifuge to remove oils safely from plants, without waxes.
Here is one of the most thought out and well designed centrifuge out there. It will not only make a safe and clean extraction of plants, it makes it easy and fast.
While it’s top of mind, grab the detailed spec sheet by clicking the purple button. That will also provide you a way to connect with questions.
What Makes This Centrifuge Great
Grab the specification or cut sheet by clicking the button above and entering your email address. Â
Speed Processing
Sometimes you may just have to process 2000lbs in a 24 hour period. This centrifuge built to extract at warp speed using our dynamic shear tech. Other efficiencies built in are features for quick cleaning, stored recipes and 780 G’s of drying power. 75% larger than comparable 15lb centrifuges.
Easy To Use
Ergo-latches, the wireless smart control panel and quick maintenance design make this one of the easiest machines to run in a lab. The double mechanical seal is the most reliable centrifuge seal. Swap cartridge seals to use with water, ethanol, heptane, pentane and other solvents.Â
Â
Craftsmanship & Design
This is one of the few extraction centrifuges built from the ground up in the USA by experienced centrifuge welders, CNC machinists and engineers. Customer feedback has influenced design, along with providing you the ability to make the cleanest products, in a repeatable and safe way.
Additional Specifications
Explosion proof motors are equipped to contain an explosion that may occur inside a motor, as well as prevent explosive gases and vapors from being released into the environment. Its robust construction meets the UL and CSA
listed Hazardous Locations requirements. This product line is designed for use in Class I, Division 1, Group D, and Class II, Division 1, Groups E, F, and G and carries a temperature code rating of T3C (160ËšC).
- C1D1 NEMA XP MotorÂ
- 5HP, 3.7kW
- Full Load Amps 13.9
- 230/460 3 Phase
- Continuous Duty
- 1.15 Service Factor
- TEFC
- Oversized 300 Series Bearings
- Non-Sparking Brass V-Ring Slingers
- Corrosion-Resistant ASTM Grade 5 Hardware
Basket is 17″ Diameter
Basket Volume 17 gallons
